I.T GRADE SERVER RACK/CABINETS

Network & I.T Grade Server racks/cabinets

Start by thinking about how you plan to use your servers. Then move on to looking into the different options that are currently available. Once you know how wide, high and deep your servers and related accessories will be, you’ll be able to choose a suitable server rack that does everything you need it to do.

Whether you’re thinking about ways to build the server your business needs for its grand expansion plans, or you’re looking for a more understated option to suit your home or small business needs, there are plenty of great options for you to choose from.

Server racks come in a huge range of sizes, so it’s easy to become overwhelmed by the options when you first start thinking about how to build a server. However, there are a few general rules that you can use to decide on the best server rack sizes for your requirements.

Feautures::

● Welded frame, reliable structure;
●Standing or wall mounting installation;
●Adjustable feet and heavy duty castors are optional;
● Easy mounting installation (patent);
● 19” standard installation;
● Removable side panels, side locks optional;
● Cable entry on both of top cover and bottom panel;
● 120mm fan available;
●Turning angle of front dooris over 180 degrees .
● Main material: SPCC cold rolled steel;
● Thickness: mounting profile 2.0mm, mounting angle 1.5mm, others 1.2mm.
● Surface finish: Degreasing, pickling, phosphoric, powder coated;
● Degree of protection: IP20
● Loading capacity: Static loading: 60KG

Feauture 2

● Exquisite design with precise dimension and craftsmanship;
●Toughened glass door with silk-screened flower pattern,
●Vented front door border and rear door;
● Adjustable feet and heavy duty castors are available simultaneously;
● Cable entry on the top cover and bottom panel with adjustable sizes;
● Optional installation of plinth to enable cabinets fixation, under-base cable entry/ventilation;
● Efficient and reliable cabinet connection by baying kit; Removable side panels to ease maintain;
● Around 1/3 assembled original volume when flat pack
● Main material: SPCC cold rolled steel
● Thickness: mounting profile 2.0mm, mounting angle 1.5mm, others 1.2mm.
● Surface finish: Degreasing, pickling, phosphoric, powder coated;
● Degree of protection: IP20
● Loading capacity: Static loading: 800KG

Standards:

● Comply with ANSI/EIA RE-310-D IEC60297-2 DlN41494: Part1 DIN41494: part7 Rohs and CE
